MGBS Extended with M12 plug connector

The new MGBS Extended locking modules featuring two 8-pin M12 connectors expand our
product portfolio and are available to order.

In these new versions, the pin assignment of the X1 connector is compatible with the widely
used CTP and MGBS with an M12 8-pin connector.

The X2 connector is additionally assigned
with the signals from the control elements. This allows existing applications without integrated
control elements to be supplemented quickly and easily.

LineLIGHT Fusion seLineLIGHT Fusion sets new standards in the field of in-tegrated signalingts new standards in the field of in-tegrated signalingWERMA Signaltechnik is delighted to have received a special a-ward: the "LineLIGHT Fusion" series has been awarded the prestigious iF DESIGN AWARD 2025. For over 70 years, this award has been aLineLIGHT Fusion sets new standards in the field of in-tegrated signaling globally recognized seal of quality for outstanding product design.

Contactless Detection of Objects

Photoelectronic sensors can detect or count objects without contact, measure distances and detect colors, gloss or luminescence using light. The additional connection of special fiber-optic cables permits their use in extreme conditions such as cold, heat or limited space.

Safety edges

Safety edges are sensors that protect shearing and crushing edges against pinching hazards. If the safety edge encounters an obstacle, for example if a hand gets caught in a closing door, the automatic movement is stopped immediately.

We offer Safety Edges as normally open contacts or normally closed chains, depending on the switching principle.

With the safety edge self-assembly, we give you the opportunity to manufacture your safety edges quickly and inexpensively yourself.

 Application as
- Locking system: When the key is removed, the system is safety locked. An unintentional start of the system is prevented.

- Authorization system: Safe selection of an operating mode
- Key transfer system

 Short description
- Key (transponder) with high coding level (same key type as for the existing CKS-A-L1B-SC key system)
- Mechanical detend mechanism of the inserted key
- Connection via M8 plug connector
- External evaluation of the transponder signals
- LED display (green) when a valid key is detected
- Installation in standard assembly hole Ø 22,5mm

The MB-40 machine light offers the option of dimming using a PWM signal, supported for example by the MB-DIM. On the other hand, the MB-41 is characterized by its function, which enables load-free switching.
